- Frequency Range:30-1000Hz
- Voice Coil Material:CU
- Voice Coil Diameter:2.5inch
- Former Material:Black Aluminum
- Basket Material:Stamp Steel
- Cone:PP Theated Paper Cone
- Magnet:2*50 OZ
- Sensitivity:75 - 90dB
- Voltage:DC 12V
- Place of Origin:CN;ZHE
- Size:15 Inch,12 Inch,10 Inch
- Impedance:Dual 4 Ohm
- Brand Name:DT AUDIO
- Model Number:SUB-1214
- Warranty:12 Months
| Model | SUB-1514 | SUB-1214 | SUB-1014 |
| Nominal Diameter(inch) | 15 | 12 | 10 |
| Nominal Impedance(ohms) | 4+4 | 4+4 | 4+4 |
| Norminal Power Handling(W) | 400 | 400 | 300 |
| Porgrame Power Hanlding(W) | 800 | 800 | 600 |
| Sensitivity(1W/1M)(dB) | 89 | 88 | 87 |
| Frequency Range(Hz) | 30-700 | 32-800 | 45-1000 |
| Voice Coil Material | CU | CU | CU |
| Voice Coil Diameter(inch) | 2.5 | 2.5 | 2 |
| Former Material | Black Aluminum | Black Aluminum | Black Aluminum |
| Basket Material | Stamp Steel | Stamp Steel | Stamp Steel |
| Cone | PP Threated Paper Cone | PP Threated Paper Cone | PP Threated Paper Cone |
| Magnet | 2*50 OZ | 2*50 OZ | 2*40 OZ |
